全数字化星载信号处理载荷架构设计
Design of fully digital spaceborne signal processing payload architecture
-
摘要: 面对商业航天新业态的迅猛发展，围绕高可靠、高效率、高效益的航天发展目标，针对卫星有效载荷的载荷核心——星载信号处理载荷部分，参考美国国家航空航天局的空间无线电通信体制设计思路，以硬件平台化、功能软件化、软件构件化为特征基础，通过对软硬件体系、载荷时频、重构方式、资源共享等多元化的设计，构建了一种灵活、通用、易扩展、需求适应强的全数字化星载信号处理载荷架构。相比于传统星载信号处理载荷，采用该架构设计的星载信号处理载荷可以广泛适应各类星载信号处理的需求，极大地提升有效载荷的信号处理能力及可靠性，降低载荷的研制周期与成本，为未来卫星有效载荷的软件化、网络化、智能化发展提供技术支撑。Abstract: In the face of the rapid development of new commercial aerospace formats, focusing on the aerospace development goal of high reliability, high efficiency and high benefit, in view of the satellite payload part load core - satellite signal processing load, this paper refers to the design idea of NASA's STRS system, based on the characteristics of hardware platform, software function, and software component, through the diversified design of hardware and software system, load time and frequency, reconstruction mode and resource sharing. A flexible, versatile, scalable and adaptable payload architecture for satellite-borne signal processing is constructed. Compared to traditional spaceborne signal processing load, the use of the architecture design of spaceborne signal processing load can be widely used to all kinds of spaceborne signal processing requirements, greatly improve the payload of the signal processing ability, and reliability, effectively reduced the load of the development cycle and cost, for the future satellite payload software, network and intelligent development to provide technical support.
-
Keywords:
- satellite application /
- full digitalization /
- signal processing /
- architecture design
-
-
[1] SPACE TELECOMMUNICATIONS RADIO SYSTEM (STRS) ARCHITECTURE STANDARD:NASA-STD-4009[S].NASA,2018. [2] QUINN T,KACPURA T. Strategic adaptation of Sca for strs[C]// 2006 Software Defined Radio Forum Technical Conference. 2007. [3] 赵军锁,吴凤鸽,刘光明,等.发展软件定义卫星的总体思路与技术实践[J].卫星与网络,2018,181(4):44-49. [4] 邢卓异,朱舜杰,黄晓峰,等.软件定义航天器系统架构设计[J].航天器工程,2021,30(5):1-8. [5] 楼才义,徐建良,杨小牛.软件无线电原理与应用[M].2版.北京:电子工业出版社,2014:121-129. [6] 范占春,董世林,鲁帆,等.一种星载多功能可重构终端设计[J].计算机测量与控制,2022,30(4):149-154. [7] 张晓波,王赞,史劼,等.一种新型航天综合化载荷架构研究[J].中国电子科学研究院学报,2017,12(5):551-555+562. [8] 王兴龙,董云峰.即插即用模块化卫星体系结构研究[J].航天器工程,2012,21(5):124-129. [9] 王时雨,张盛兵,黄小平,等.星载SAR成像与智能处理的单片多处理架构[J].西北工业大学学报,2021,39(3):510-520. [10] 宋桃桃,杜长刚,邱翔,等.基于ARM处理器的空间可靠性软件架构设计与实现[J].空间电子技术,2022,19(1):44-48. [11] 孟彦春,张立新,孙云峰.新型全数字频率传递方法数学模型及算法研究[J].电子设计工程,2018,26(4):19-23. [12] 谢军,孙云峰,屈勇晟,等.空间原子钟组管理的实现及影响因素分析[J].导航定位学报,2016,4(1):16-20+49. [13] 刘红林,李英玉,杨震,等.基于能力分析的天基资源虚拟化方法的设计与实现[J].上海航天(中英文),2020,37(4):55-63. [14] 潘皓.多核虚拟化分区技术在航空电子系统中的应用[J].计算机测量与控制,2019,27(11):206-209. [15] 高杨,李浩若,何锋,等.时间触发以太网抢占式重构方案优化设计[J].电光与控制,2020,27(10):88-93. [16] 熊浩伦,闫国瑞,李国军,等.基于最小系统的小卫星在轨软件重构系统设计[J].遥测遥控,2020,41(3):48-55.
