微波无线传能发射天线馈电相位鲁棒性优化设计

柳坤鹏; 李勋; 孙小宇; 刘晨阳

doi:10.3969/j.issn.1674-7135.2024.03.007

微波无线传能发射天线馈电相位鲁棒性优化设计

西安电子科技大学机电科技研究所，西安 710071

基金项目: 国家自然科学基金项目（编号：62201416）；中央高校基本科研业务费项目（编号：QTZX23070）；秦创原引用高层次创新创业人才项目（编号：QCYRCXM-2022-314）

计量
- 文章访问数: 019
- HTML全文浏览量: 0
- PDF下载量: 033
出版历程
- 刊出日期: 2024-06-24

Robust and optimal design of the feed amplitude of transmitting antenna in microwave wireless transmission

Research Institute on Mechatronics，Xidian University，Xi’an 710071，China

摘要

摘要: 为保证微波无线传能系统具有可靠且高的传输效率，针对系统中发射天线存在的馈电相位误差，提出了一种基于最差情况分析的多准则优化设计方法。首先，推导了发射天线电性能参数与随机馈电相位误差的数学关系。其次，基于最差情况分析方法，建立了馈电相位随机误差的缩减区间描述模型。然后，提出了一种具有鲁棒性的波束收集效率优化设计方法。最后，通过蒙特卡洛方法验证了所提方法的有效性。
- 微波无线传能 /
- 波束收集效率 /
- 敏度分析 /
- 天线阵列 /
- 移相器相位误差
Abstract: To ensure a microwave wireless power transmission system with both high reliability and high efficiency, a multi-criteria optimization design technique based on the worst case sensitivity analysis was developed. First, the relationship between the electrical performance of the transmitting antenna and the random excitation phase errors is formulated. Next, a reduced tolerance range model of the excitation phase based on the worst-case sensitivity analysis is established. Then, a robust excitation phase optimization design method is proposed to ensure high and reliable beam collection efficiency. Finally, the effectiveness of the proposed method is verified by the Monte Carlo method.
- microwave wireless power transmission /
- beam collection efficiency /
- sensitivity analysis /
- antenna array /
- phased shifter error
